These plans provide conceptual information. Periodic changes in the National Design Specifications for Wood Construction, changes in building materials, snow load variations and the serious impact of deviations from the plan make it imperative that professional services be utilized to tailor these plans to your situation. Suggested services include but are not limited to: structural design; assurance of compliance with codes and regulations; supervision of site selection and construction; and provision for utilities, waste management, and access. North Dakota State University, the MidWest Plan Service, the United States Department of Agriculture, and none of the cooperating Land-grant universities warranty this plan.
Extension Agricultural Engineering, North Dakota
State University
Acquiring Plans
The 4 digit plan numbers (e.g. 5170) are plans prepared through the USDA Cooperative Farm Building Plan Exchange. Most of these plans can be downloaded, viewed & printed using Adobe Acrobat Reader. To download, view, and print using Adobe Acrobat Reader, click on the linked plan number. There is no charge for 8 1/2 x 11 inch photocopies of these plans. Full size 18 x 24 inch plans cost $4.00 per sheet. The hyphenated plan numbers (e.g. 771-2-3) are plans prepared by NDSU Agricultural Engineers. The cost for these plans is $4.00 per 18 x 24 inch sheet. The 5 digit plan numbers (e.g. 72103) are plans prepared through the Midwest Plan Service (MWPS)--a committee of agricultural engineers from the 12 North Central Midwest Land Grant Universities. MWPS plans, which are on 11 x 16 inch sheets cost $4.00. A few plans from Canadian Plan Service, American Plywood Association and other sources are included. The cost of these is $4.00 per sheet.
NOTE: If you would like to download the file to your hard drive just right-click your mouse on the hyperlink and choose "Save Link as" and then choose a directory on your harddrive to save the file.
| B = | basement | GbR = | gableroof | ShR = | shedroof |
| CB = | concrete block | GV = | gravity ventilation | SO = | side opening |
| CF = | concrete floor | H = | high | StW = | stud wall |
| CG = | gablecombination roof | ML = | materials list | TR = | truss rafter |
| CSF = | concrete slat floor | NTR = | nailed truss rafter | W = | wide |
| D'BL = | double | OH = | overhead | WC = | wood construction |
| F = | fireplace | PB = | post-beam | WF = | wood floor |
| GaR = | gambrelroof | RWF = | raised wood floor | WSF = | wood slat floor |
| * = may need to be photocopied
(large plan, charge $4.00 per page) |
** = No plan on file | ? = Obsolete plan (May not
be
available) |
Plans can be located quickly in
this list by using the "Find" option in your browser to find key
words. Use the 'Ctrl + F' shortcut in both Internet Explorer
and Netscape to bring up the "Find" box.
| TITLE | PLAN # | YEAR | # ofpages | MISC. PLAN | 8 X 11 |
| CATTLE BREEDING RACK, 9X4X4, WOOD CONSTRUCTION ON SKIDS | 5037* | '49 | 1 | 754 | X |
| SWINGING 16' GATE, 1" BOARD CONSTRUCTION | 5064 | '33 | 1 | X | |
| HAY FEEDER RACK, 7'X29'X10', V BOTTOM, WOOD POST F'DN | 5101* | '22 | 1 | ||
| BULL PEN, 14'X18', GABLEROOF BARN, 16X50 OUTSIDE PEN | 5143* | '46 | 1 | 754 | X |
| GENERAL BARN, 16X30, 2-STORY, GABLE OR GAMBREL ROOF | 5167 | '46 | 1 | X | |
| BARN, 2 STORY, GAMBREL ROOF, 32'X32', PEN DETAILS | 5222/6* | '33 | 5 | ||
| BARN, 18X32, 3 COWSTALLS, ShR, 2 PENS, GRAVITY VENTILATION | 5227/8* | '33 | 2 | ||
| BARN, GABLEROOF, 1 OR 2 STORY, 4 COWSTALLS, 4 PENS, GRAV VENT | 5229/32* | '33 | 4 | ||
| BARN, 34X60, GaR, 2-STORY, STALL & PEN DTLS, GRAVITY VENT. | 5233/7* | '33 | 5 | ||
| BARN, 36'X64', GaR, STALL-PEN DETAILS, GRAVITY VENT | 5238/42* | '33 | 5 | ||
| DAIRY BARNS, 32, 34 & 36 W, GaR, 2-STORY, ALT. LAYOUTS | 5246/60* | '33 | 1 | 5 | |
| MILKHOUSE, 7X7X7, SHEDROOF, WOOD FRAME, CAN-COOL SYSTEM | 5353* | '33 | 1 | ||
| MILKHOUSE, 11X11X8, GABLEROOF, CONC. BLOCK, CAN-COOL SYSTEM | 5354* | '33 | 1 | ||
| MILKHOUSE, 12X14, GABLEROOF, WOOD FRM OR CB, CAN-COOL SYSTEM | 5355/7* | '33 | 3 | ||
| MILK BOTTLING BLDG, 14X24+ANNEX, GABLEROOF, WOOD FRAME | 5358/60* | '33 | 3 | ||
| CREAMERY, 32X73, FLAT ROOF, COLD STRG, COAL HEAT | 5361/5* | '33 | 5 | ||
| CREAMERY, 42X72, HIPROOF, OFFICES, STORAGE, COAL HEAT | 5366/8* | '33 | 3 | ||
| MILKING BARN, 20X40; 6 WALK-THRU STALLS, PEN DTLS, GV | 5369/72* | '33 | 4 | ||
| BREEDING RACK FOR COWS, 4'X10' WITH STANCHION | 5375* | '33 | 1 | ||
| CATTLE FEED BUNK, 4'X12', LEGS, PORTABLE | 5376* | '33 | 1 | ||
| CATTLE HAY AND GRAIN FEEDER, 4'X12'X6', LEGS, PORTABLE | 5377* | '33 | 1 | ||
| BULL PEN DETAILS, 16'X50', W/10'X16' ShR BARN, FENCE DET. | 5403/4* | '33 | 2 | ||
| HAY FEEDER, 4'X15'X5', VEE-SHAPED FEEDSPACES, SKIDS | 5463 | '31 | 1 | ||
| HAY FEEDER, 6.5'X22'X8', HOPPERED-SLATTED RACK, SKIDS | 5464 | '31 | 1 | ||
| AUTOMATIC GATE, 5'X15', MANUAL-PULL LEVER-OPERATED | 5467 | '34 | 1 | ||
| WOOD GATES 5 TYPES, STILES & FENCE PASSAGEWAYS 3 TYPES ('39) | 5505 | '87R | 1 | 764 | X |
| GENERAL BARN, 32'X36', 2 STRY, POST-BEAM GABLEROOF | 5552 | '40 | 1 | X | |
| DAIRY BARN, 30'X40', 10 STALLS +4 BX STALLS, 2 STRY, GaR, GV | 5554 | '40 | 2 | X | |
| CALF PENS, 3'-4'X 5'-6'OR STALLS, WSF, STANCHION DETAILS, WC | 5624* | '46 | 1 | ||
| DAIRY BARN LAYOUTS, 34'W, FACE-IN OR OUT STANCHIONS ('47) | 5628* | '49R | 1 | ||
| DAIRY BARN LAYOUTS, 36'W, FACE-IN OR OUT STANCHIONS ('47) | 5629* | '49R | 1 | ||
| DAIRY BARN LAYOUT ALTERNATES, 38'W, FACE-IN/OUT, SIZE TABLES | 5630 | '49R | 1 | ||
| SALT BOX, 3'X5' HIGH, 1-SIDE ACCESS, POST-FRAME | 5655* | '48 | 1 | ||
| SALT BOX, 3'X6' HIGH, 1-SIDE ACCESS, POST-FRAME | 5656* | '48 | 1 | ||
| COW STALL DET, TIE OR STANCHN, FLAT DEPRESSED OR RASD MANGER | 5661 | '88R | 1 | X | |
| CATTLE LOAD CHUTE ON 2 WHEEL AXLE, 4'X8'X5' | 5681* | '48 | 1 | X | |
| MILKHOUSE LAYOUTS FOR CANS, GABLEROOF, CONC. BLOCK OR StW | 5683* | '49 | 2 | ||
| MILKHOUSE, 16X36, W/BOILER & COOLER RM, GABLEROOF, CB | 5685* | '48 | 1 | ||
| MILKHOUSE, 10X14, GABLEROOF, CONCRETE BLOCK WALLS | 5686* | '48 | 1 | ||
| DAIRY BARN WIRING AND LIGHTING LAYOUTS | 5698* | '49 | 1 | ||
| MILKING CENTER, 17'X45', 3 SO STALLS, CG, CB, RAMP | 5735 | '52 | 2 | ||
| MILKING CNTR, U-TYPE, 18X19, 3 MH LAYOUTS, GAMBREL ROOF, CB | 5736* | '59 | 3 | 817 | X |
| GENERAL BARN, 20X38, 1.5 STRY, GaR, 4 COWS, 1 HORSE, STORAGE | 5747 | '49R | 1 | X | |
| CATTLE FEEDING BARN, 82'W X VAR.LGNTH, GbR DETAILS, PB | 5765 | '52 | 2 | ||
| CATTLE FEEDING BARN, 82'X60', POSTBEAM GbR, MG'R DETAILS | 5765-A | '56R | 3 | ||
| SILAGE & GRAIN FEED BUNK, 3'X10', V-BOTTOM/LEGS | 5766* | '52 | 1 | ||
| CATTLE FENCELINE FEED BUNKS, PLANK, STRAIGHT OR SLOPED SIDES | 5767* | '53 | 1 | X | |
| HAY RACK, 4'X14', V-TYPE NECKRAILS, SKIDS | 5772* | '51 | 1 | 747 | X |
| CATTLE SELF FEEDER, 6'X8'X8', GbR, 80 BU. ON 4 WH'LS | 5776* | '53 | 1 | X | |
| HAY FEEDER, V SLAT OR V FEED FENCE 4'X14', SKID OR WHEEL DET | 5777* | '54 | 1 | X | |
| CATTLE SELF FEED FENCES, 8 TYPES FOR BUNKER OR TRENCH SILOS | 5801 | '55 | 1 | X | |
| CATTLE MANGERS & FEEDING FLOORS, 5 TYPES, CONCRETE FLOOR | 5837 | '57 | 1 | 782 | X |
| DAIRY BREEDING STALLS, 3 COWS SIDE/SIDE, ShR, WOOD | 5840 | '57 | 1 | 786 | X |
| MILKING STALL, 3'X8'X5', SIDE ENTER TYPE, PIPEFRAME | 5846 | '58 | 1 | 790 | X |
| CATTLE FEEDBUNK, 4'W PLANK SIDES, 26'W UMBRELLA,GbR, CF('58) | 5862 | '88R | 1 | 802 | X |
| FEEDBUNK, 4'W, 24'W UMBRELLA GbR ON POLE BUNK FRAME, C. SLAB | 5864 | '58 | 1 | 813 | X |
| MILKING CENTER, 16X23, 30' OR 36' HERGBONE+16X30 MH, GbR, CB | 5868 | '59 | 3 | 818 | X |
| CATTLE SELF FEED FENCES-3 TYPES FOR BUNKER SILOS, PORTABLE | 5872 | '59 | 2 | 846 | X |
| MILKING PLANT, 17'X41', 3 SIDE OPENING STALLS, GbR, CB, CF | 5875 | '60 | 2 | 937 | X |
| DAIRY LOOSE HOUSING & SELF FEED LAYOUT/STORAGE FOR 40 COWS | 5880 | '60 | 1 | X | |
| DAIRY LOOSE HOUSING LAYOUT, 2 BARNS, MILK CENTER, BUNK SILOS | 5881 | '60 | 1 | ||
| DAIRY LOOSE HOUSING & MECH. FEED SYSTEM, STORAGE FOR 40 COWS | 5882 | '60 | 1 | X | |
| DAIRY LOOSE HOUSING LAYOUT USING OLD BARN, MILK CENTER | 5883 | '60 | 1 | ||
| DAIRY LOOSE HOUSING LAYOUT, CH. HAY STRG-FEEDER, BUNK SILO | 5884 | '60 | 1 | ||
| FREE STALL DAIRY HOUSING/FEEDING SYSTEM, 150 COWS | 5885 | '64 | 1 | X | |
| MILKING CENTER LAYOUT, L-SHAPED, 3 SO STALLS, GbR, STEPS | 5889 | '60 | 1 | ||
| MILKING CENTER LAYOUT, 19'X46', 4/SIDE HB, STEPS | 5891 | '60 | 1 | ||
| MILKHOUSE LAYOUT, 14'X22', GABLE OR FL. ROOF | 5894 | '60 | 1 | ||
| CATTLE FEED DISTRIBUTION, FROM UPRIGHT SILOS, 5 SYSTEMS | 5896 | '60 | 1 | X | |
| MATERNITY & CALF BARN LAYOUT, 34'X60', CENTER ALLEY | 5898 | '60 | 1 | ||
| DAIRY BARN LAYOUT, 36'W & VAR.LNGTH, FACE-OUT STALLS | 5901 | '60 | 1 | ||
| CHOPPED HAY SELF-FEEDER WAGON, 6'X20'X6' | 5908 | '60 | 1 | 883 | X |
| CATTLE HAY FEEDRACK, 4'X16', ROOFED, SKIDS ('61) | 5925 | '88R | 1 | 1027 | X |
| CALF PENS USING GATES, 4'X8' PORTABLE, STEEL OR WOOD CONST. | 5933 | '61 | 1 | 1043 | X |
| 40 COW BARN/FAMILY FALLOUT SHLTR, 51X110, PB, GbR, SIDE SILO | 5937 | '62 | 3 | 943 | X |
| 40 COW BARN/FAMILY FALLOUT SHLTR, 51X110, PB, GbR, END SILO | 5938 | '62 | 3 | 943 | X |
| FDBUNK, PLANK, 25'W UMBRELLA GbR SUPPORTED W/CENTR BUNK POST | 5939 | '62 | 1 | 979 | X |
| 50 STALL FACE-OUT TIE STALL BARN-FALLOUT SHELTER, 36X152 | 5953 | '64 | 5 | 989 | X |
| 66 COW FREESTALL BARN/FALLOUT SH, 45X91, PB,GbR, SL. ALLEYS | 5954 | '63 | 2 | X | |
| 66 COW FREESTALL BARN/FALLOUT SH, 45X91, PB, GbR, SC. ALLEYS | 5955 | '63 | 2 | X | |
| FREESTALLS, SLANT OR STRAIGHT POSTS, PLANK PART, DIRT FLOOR | 5956 | '63 | 1 | X | |
| CATTLE GATES & FENCES, METAL & WOOD, MANGATES | 5961 | '63 | 1 | X | |
| CALF BARN, 8X40 + 8X12 FEEDROOM, PENS, POST-BEAM SHEDROOF | 5970 | '64 | 2 | 1333 | X |
| DAIRY FREESTALLS, MANURE RAMP CONCRETE FEEDBUNK & HAY FEEDER | 5977 | '65 | 1 | 1068 | X |
| 100 COW FREESTALL BARN, 48X156+7'OH & MILK CNTR, TR & POSTFR | 5985 | '65 | 3 | 1037 | X |
| SILAGE FEEDBUNKS, 2 CONCRETE, 2 PLANK W/1 ROW POST, GbR | 6012 | '88R | 1 | 1104 | X |
| DAIRY FREESTALL LAYOUTS, 35 TO 154 COWS, 48'W BARN, NTR, GV | 6023 | '67 | 4 | 1115 | X |
| FREESTALL BARN, 48X89, HAY STRG 25X96 & FEED AREA +MILK CNTR | 6025 | '67 | 1 | 116 | X |
| SLOT VENTILATION CEILING/WALL AIR INLETS, 3 TYPES, ADJUSTAB | 6028 | '67 | 1 | X | |
| 60 COW FREESTALL RESTING BARN, 40X72, TR, SCRA. CROSS ALLEY | 6030 | '67 | 1 | 1125 | X |
| 124 COW FSTALL BARN, 82X148, 50'TR+16' LEANS, CN'TR BUNK, GV | 6031 | '67 | 4 | 1132 | X |
| MILKHOUSE W/UTILITY RM LAYOUT, GABLEROOF, STUDWALL, CF | 6033 | '67 | 1 | 1113 | X |
| 62 COW FREESTALL BARN, 40X155+MILK/HOSP CNTR, WALLBUNK, CF | 6034 | '67 | 1 | 1130 | X |
| 114 COW FSTALL SYSTEMS, 80X168, 32'TR+LEANS, UPRT SILO,SCRAP | 6035 | '67 | 2 | 1127 | X |
| DAIRY CIRCULAR AUTO CROWD PEN, 45-100 COWS, METAL | 6037 | '67 | 1 | 1119 | X |
| 50 COW FREESTALL RESTING BARN, 40X60X9, CROSS-ALLEY, NTR | 6039 | '67 | 2 | 1128 | X |
| 60 COW FREESTALL BARNS, 44'W TR OR 48'W PB W/SINGLESLOPE TR | 6042 | '67 | 2 | 1137 | X |
| ROUGHAGE SELF-FEEDER, 6X16X5, 2-WH-AXLE, PLANK & PLYWOOD | 6045 | '68 | 1 | 1124 | X |
| 72 COW FREESTALL RESTING BARN, 50'W, PB, GbR, SCRAPED CF | 6050 | '68 | 1 | 1135 | X |
| ELEVATED CALF STALLS, 8X14, METAL, SKIDS | 6052 | '68 | 1 | 1138 | X |
| CALF STALL UNITS, 5X8, WOOD, PORTABLE | 6057 | '68 | 1 | 1149 | X |
| MILKHOUSE, 16X20X8, GABLEROOF, STUDWALL, INSUL, CF, ELEC. | 6063 | '69 | 3 | 1169 | X |
| CALF SHELTER, 12'X19'X8', SHEDROOF, SKIDS | 6065 | '69 | 1 | 1163 | X |
| CATTLE FEED BUNK, 3'X12', PORTABLE, SUPPLEMENT FEEDER | 6066 | '69 | 1 | 1158 | X |
| D'BL ROW FREESTALL BARN, 16'W X V.LNGTH, STALL DET., PB | 6067 | '69 | 2 | 1156 | X |
| MILKHOUSE, 20X24, BATH & UTILITY, GABLEROOF, STUDWALL | 6078 | '69 | 2 | 1183 | X |
| DAIRY CROWD GATES-2 TYPES FOR ALLEYS, MOTOR DRIVEN | 6092 | '70 | 2 | 1197 | X |
| HEIFER FREESTALL BARN, 34' OR 40'W X VAR LNGTH, ALT LAYOUTS | 6102 | '70 | 4 | 1219 | X |
| 200 COW FSTALL BARN, 84X236, 36'TR+24'TR LEANS, WAGON FEED | 6111 | '71 | 3 | 1241 | X |
| 42 COW FREESTALL BARN, 56X84, RAISED DRIVE-THRU, PB GbR | 6112 | '71 | 2 | 1236 | X |
| DAIRY FREESTALL BARN SYSTEMS, 74 TO 296 COWS, MILKCENTER | 6113 | '71 | 3 | 1238 | X |
| MILKING CENTER LAYOUTS; 6, 8 & 10 DBL HB, TRUSS RAFTER, CB | 6132 | '71 | 2 | 1260 | X |
| 2 CALF STALLS, 43"X58", RSED WSF, PLYWOOD SIDES, PIPE LEGS | 6138 | '72 | 1 | 1269 | X |
| SELF FEEDER SILAGE WAGON RACK, 6'X16', PLANK CONST. | 6143 | '72 | 1 | 1305 | X |
| DAIRY MATERNITY BARN, 34X72, PENS AND STALLS | 6146 | '72 | 2 | 1311 | X |
| DAIRY CALF NURSERY, 18X48, 40 CALVES, GbR, StW, FL. GUTTER | 6164 | '73 | 2 | 1326 | X |
| COW KENNELS OR COVERED FREESTALLS, 4X7X8, SHEDROOF | 6165 | '73 | 1 | 1344 | X |
| SILAGE FEEDBUNKS, COVERED, W/4 BUNK TYPES & 4 ROOF TYPES | 6167 | '88R | 1 | 1346 | X |
| MILKHOUSE, 16'X22', GABLEROOF, StW, BATH & UTILITY ROOM | 6174 | '73 | 2 | 1333 | X |
| CALF HUTCH, 4X8X4, SOLID SIDES, FEEDBOX | 6180 | '74 | 1 | X | |
| CALF BARN, 22'X40', GABLEROOF, CB, ELEVATED STALL DETAILS | 6186 | '74 | 3 | 1352 | X |
| CATTLE BREEDING STALL & BOXSTALL, 8X12, HEADGATE, PIPE CONST | 6194 | '75 | 1 | ||
| 44 COW FREESTALL BARN, 48X128 & MC, POST-BEAM, WALL FEEDBUNK | 6196 | '75 | 3 | 1389 | X |
| CALF STALL UNIT, 4'X5', ELEVATED, PAIL, HAY & GRAIN FEEDING | 6199 | '75 | 1 | X | |
| CALF STALL UNIT, 4'X5', ELEVATED, PAIL FEEDING ONLY, WOOD SL | 6200 | '75 | 1 | X | |
| MILKING CENTER, 24X36+DBL 6 OR 8 HB MLK STALLS, CONC. BLOCK | 6203 | '75 | 3 | X | |
| PASTURE DRAGS USING OLD TIRES, 2 & 3 ROW ARRANGEMENTS | 6212 | '75 | 1 | X | |
| HAY FEEDERS FOR BIG BALES, REC'T OR R'ND SHAPED, METAL/WOOD | 6214 | '75 | 1 | X | |
| DAIRY FREESTALL SYSTEM, 166X368, 4-52 COW GRPS, FLUSH ALLEY | 6218 | '75 | 2 | 1389 | X |
| FREESTL REST BARN, 22'W, GbR, DBL ROW;OR 12'W, ShR, SG'L ROW | 6224 | '75 | 1 | X | |
| CATTLE MINERAL SHELTER, 12X12X8, SHEDROOF, SKIDS | 6226 | '75 | 1 | X | |
| DAIRY HEIFER BARN, 40'W+0UTSIDE PENS, 5 LAYOUTS, 55-105 HEAD | 6234 | '75 | 5 | X | |
| HAY FEED PANELS, 8' TO 16' L, METAL, SLANTED NECKRAIL, PT'BL | 6242 | '76 | 1 | X | |
| COVERED HAY FEEDER FOR 2 ROUND BALES, 8X12, METAL, PORTABLE | 6245 | '76 | 2 | X | |
| COVERED HAY FEEDER FOR 2 R'ND BALES, 7X14, WOOD, SL NECKRAIL | 6249 | '76 | 1 | X | |
| 96 COW FREESTALL REST BARN, 48X96X10, TR, POLEFRAME, SCRAPED | 6250 | '76 | 2 | 1389 | X |
| GOAT MILKING CENTER, 23X28, 10 GOATS, GABLEROOF, StW, CF | 6255 | '77 | 2 | X | |
| GOAT MILKING CENTER, 18X39, 10 GOATS, GABLEROOF, StW, CF | 6256 | '76 | 2 | X | |
| GENERAL BARN, 19X31X12, GbR, MOW, 2 BXSTLLS, WALK DOOR, CF | 6267 | '76 | 1 | X | |
| GENERAL BARN, 24X30X12, GbR, MOW, 2 BXSTALS, SL DR., CLAY FL | 6268 | '77 | 1 | X | |
| CALF BARN, 16X60+OUTSIDE PENS & FEEDROOM, 15 PENS, CG | 6271 | '77 | 2 | 1404 | X |
| 80 COW FSTALL BARN, 40X171+MC, NTR, CSF OVER MAN STRG, INSUL | 6281 | '77 | 1 | 2 1389 | X |
| 40 COW FREESTALL BARN, 42X81X9+MC, CENTER FEEDBUNK, INSUL,CF | 6292 | '78 | 7 | 1389 | X |
| GUTTER GRATE DESIGNS, 5 TYPES, 5/8 D. ROD & ANGLE IRON | 6299 | '78 | 1 | X | |
| BUCK GOAT YARD FEEDER, 2'X6', ShR, CABLE TETHER SYSTEM | 6300 | '78 | 1 | X | |
| CALFHUTCH, 4'X7'X4', PLYWOOD, ShR, MOVABLE, MESH PEN SIDES | 6301 | '78 | 1 | 1404 | X |
| CALF PEN UNIT, 12X12, 4 PENS, SOLAR SHEDROOF, SKIDS | 6302 | '78 | 1 | 1404 | X |
| COW TRIM CHUTE, 3X8X5, PIPEFRAME, MOVABLE | 6303 | '78 | 1 | X | |
| HAY STRG-FEED BARN, 63'W X V. LNGH, GABLEROOF, POLE FRAME | 6310 | '78 | 2 | X | |
| 78 COW FREESTALL BARN, 44X120, WALL FEEDBUNK, 4 BARN SYSTEM | 6313 | '78 | 3 | 2 | |
| 50 COW FACE-IN TIESTALL BARN, 40'X180', TR, DRIVE-THRU FEED | 6326 | '80 | 2 | X | |
| MILKING CENTER, 28'X32', TR, 3 SIDE-0PEN MILKSTALLS, CB | 6331 | '81 | 2 | X | |
| 200 COW FREESTALL SYSTEMS, 90'W, 3 ARRANG, 6 ROW DRIV-THRU | 6339 | '82 | 4 | X | |
| SUPER CALF HUTCH, 12X19X7, SHEDROOF, STUDWALL, SKIDS, HD'GTE | 6342 | '81 | 1 | X | |
| FEED CARTS, 2X4 OR 6X2-1/2, PLYWOOD ('82) | 6343 | '84R | 1 | X | |
| MILKCENTER, 12 STALL TRIGON, 32X50, GbR, CB, MILKER PIT | 6348 | '83 | 2 | X | |
| DAIRY FREESTALL SHADE SYSTM, 46'X48', ShR, PB, C. ALLEY | 6357 | '83 | 1 | X | |
| MILKING & COW TREATMENT CNTR, 42X68, W/DBL 6 HB, TR, INSUL. | 6359 | '84 | 4 | X | |
| SWINGING GATE, 4' TO 12' WIDE ADJ. HEIGHT, PIPEFRAME | 6365 | '84 | 1 | X | |
| CALFBARN, 10X80X7, OPEN FRONT, ShR, POLEFRAME, 4X14 PENS | 6373 | '85 | 1 | X | |
| SOLAR CALFHUTCH BARN, 24'W, ShR, POST-BEAM, POSTS 6'OC | 6374 | '85 | 2 | X | |
| SOLAR CALFBARN, 20X144, SHEDROOF, REMOVABLE PEN ENDS | 6377 | '86 | 2 | X | |
| 62 TIESTALL BARN, 38X144X8, TR, POSTFRAME, INSUL, GUTTER CL. | 6378 | '86 | 4 | X | |
| HAYBUNK, SELF-FEED, SLOPE FLOOR, W/SLANT NECKRAIL | 6385 | '87 | 1 | X | |
| MILKING PARLOR ELECTRIC GROUNDING SYSTEM | 6387 | '87 | 2 | X | |
| 102 COW FRTL BARN, 44X168, 6'OVRHNG ABVE WALL FDBUNK,TR,PFRA | 6393 | '87 | 3 | X | |
| GOAT MILKING STAND, 2X4X4, SQ. TUBESTEEL CONST., MESH FLOOR | 6399 | '88 | 1 | X | |
| 4 GOAT HB PARLOR & CHEESE PLANT, 24X28, C. BLK, STANCHN DET | 6405 | '88 | 2 | X | |
| 10 TON HOPPERED PLYWOOD BIN, 8X8X18, StW, CONC. FDN | APA 62-230 | A** '62 | 1 | 2 | X |
| UTILITY BLDG, 28'W, TR OR PB 12'OC, END & SIDE DOORS, ML | APA 63-530 | ** '63 | 4 | X | |
| MILKCENTER, OFFICE & WASHROOM, 18X42, StW/POLES | CAN 2126* | '71 | 4 | ||
| CALF PEN, 3X6, ELEV., SLAT FL., PAIL FEED | CAN 2165 | '71 | 1 | ||
| 60 HD. CALFBARN, 36X56X9, TR, StW, INSUL, CF ('67) | MW 72341** | ? '78R | 4 | X | |
| 48 HD. CALFBARN, 36X56X9, TR, StW, INSUL, CSF OVER MANRE STG | MW 72342** | ? '74 | 4 | X | |
| 40 HD. CALFBARN, 28X40X8, TR, StW, INSUL, CSF | MW 72344** | ? '78 | 4 | X | |
| 62 COW FREESTALL BARN, 42X136+MC, TR, POLEFRAME, CONV. FEED | MW 72352** | '74 | 4 | X | |
| 64 COW FREESTAL BARN, 44X120+MC, TR, POLEFRAM, WALL FEEDBNK | MW 72353** | '74 | 4 | X | |
| 200 COW FREESTALL BARN, 42X376+MC, TR, POLEFRAME, CONV. FDNG | MW 72354** | '74 | 4 | X | |
| 206 COW FREESTAL BARN, 86X240+MC, 38'TR+24'LEANS, WAGON FDNG | MW 72355** | '74 | 4 | X | |
| 100 COW FREESTAL BARN, 76X120+MC, 28'TR+24'LEANS, CONV. FDNG | MW 72356** | '74 | 4 | X | |
| 80 COW FREESTALL BARN, 40X160 +MC, TR, StW, INSUL, CSF | MW 72357** | '74 | 5 | X | |
| 41 COW FREESTALL BARN, 42X96, TR, StW, INSUL, CONV. FDNG | MW 72358** | '78 | 4 | X | |
| 105 COW FREESTALL BARN, 40X200, TR, StW, GV, CONV. FDNG, CSF | MW 72359** | '78 | 5 | X | |
| 60 COW FS RESTBARN, 40X75, TR, POLEFRAM, GV, SCR CROSS-ALLEY | MW 72360** | '78 | 3 | X | |
| 80 COW FREESTALL RESTBARN, 48X80, TR, POLEFRAM, GV, 2 ALLEYS | MW 72361** | '74 | 4 | X | |
| 44 HD. CALFBARN, 24X72, TR, POLEFRAM, PART-INSUL, CF, SCRAPE | MW 72363** | ? '79 | 4 | X | |
| CALFBARN, 36X72, TR, POLEFRAME, GRAVITY VENT, PENS | MW 72364** | '78 | 4 | X | |
| CALFBARN, 24X80, TR, POLEFRAME, INSUL, GV, PENS, GUTTER CL | MW 72365** | '79 | 5 | X | |
| MILK CNTR, 28X28, 3 SO STALLS, OFF, TOILET, ELEC WRNG, WASTE | MW 75248** | '78 | 3 | X | |
| MILKHOUSE, 16X20, GbR, StW, INSUL C. FDN, WASTE HANDLING | MW 75265** | '75 | 2 | X | |
| MILKHOUSE, 20X24X8, OFFICE, TOILET, UTIL, ELEC, INSUL C. FDN | MW 75267** | '75 | 2 | X | |
| CATTLE BREEDING RACK & HEADGATE, 4'X10"X5'H, SKIDS | MW 77321*? | '33 | 1 | ||
| HAY FEEDER, 5'X16'X6', V-RACK W/SLAT SIDES, SKIDS | ND 2199 | '50 | 1 | ||
| STOCK RACK FOR 4 WH WAGON, 4X13X5, REMOVABLE SIDES, ML | ND 333-1-1 | '33 | 1 | ||
| OCTAGON SHAPED BARN, 68' D. W/20' CENTER MANGER | ND 721-1-3 | '68 | 1 | ||
| DAIRY BARN, 36X80, 2 STORY, GABLEROOF, CF | ND 723-1-1 | /1 '24 | 1 | ||
| DAIRY MILKING & HOUSING, 30X182 W/60X72 HAY STORAGE & FEED | ND 723-1-2 | '88 | 1 | X | |
| DAIRY CALF BARN, 62' DIAMETER, 2-STORY W/CENTER SILO 14X38 | ND 723-1-3 | '88 | 1 | X | |
| DAIRY CALF BARN & GRAIN STORAGE, 2-STORY, 54'X44' | ND 723-1-4 | '88 | 1 | X | |
| DAIRY BARN PEN SYSTEMS, 36'X60', 25 COWS, CALVES, BULL, HAY | ND 723-3-1 | '35 | 1 | ||
| FREESTALL LAYOUTS, 150 COW, 78 OR 99X192, TR AND PB GbR, CF | ND 723-7-1 | '65 | 1 | ||
| FRSTALL BARN, 44'X104' W/MILK CNTR, 46 STALS, StW, MAN STRG | ND 723-7-2 | '68 | 1 | ||
| FREESTALL & HAYBARN LAYOUT, 76 COWS, PAVED YARDSPACE | ND 723-7-3 | '68 | 1 | ||
| DAIRY BARN REMODEL LAYOUTS, 30 COW, FREESTALLS OR STANCHIONS | ND 723-7-4 | '74 | 1 | ||
| DAIRY FREESTALL BARN, 44'X128' AND CALFBARN 48X56 (OLD BARN) | ND 723-7-5 | '74 | 1 | ||
| FREESTALL LAYOUTS FOR 40 COWS, 42X108 W/MILK CNTR, MAN.STRG | ND 723-7-6 | '77 | 2 | ||
| FREESTALL REMODELING, OLD BARN, 74 COWS &HEIFERS &CALVES | ND 723-7-7 | '77 | 1 | ||
| CATTLE BARN, 76'WIDE, TWO 30' SINGLE SLOPE TR, PB FRAME | ND 724-1-0 | '61 | 1 | ||
| 32' W. POLEFRAM LIVESTOCK BARN, ShR, INTERIOR POLES,OPN SIDE | ND 724-1-1 | '55 | 1 | ||
| MILKHOUSE, 12'X12', CAN-COOLER TANK, GbR, StW | ND 752-1-0 | '32 | 2 | ||
| HAY MANGER ON BARNWALL, 2X4'S ON 9" CENTERS | ND 772-4-1 | /1 '31 | 1 | ||
| CATTLE FEEDRACK, 5'X16'X6', V-FEED PANELS, SKIDS | ND 772-5-1 | /1 '31 | 1 | ||
| MILKCOOLER, 2 CANS IN BARREL | ND 845-1-1 | * '37 | 1 | ||
| SETTLING TANK, 8'X19'X8', REINF. CONC., W/2 MANHOLES | ND 851-1-1 | '67 | 1 | ||
| CROWD-HEADGATE FOR CALVING PENS, PIPE & PLANK | ND 870-3-2 | '84 | 1 | ||
| OUTDOOR FEEDYARD RUNOFF CONTROL SYSTEM W/DIKES | ND 870-4-2 | '73 | 1 | X | |
| FEEDLOT RUNOFF CONTROL SYSTEM W/ELEVATIONS & POND | ND 870-4-4 | '73 | 1 | ||
| DAIRY CALF STALLS, 22"X4', ELEVATED, SLATFLOORS | ND 871-2-7 | '75 | 2 | ||
| MILKING PARLOR DRAW-BRIDGE, 4'X4', ALUMINUM PLATE | ND 871-2-8 | '79 | 1 | ||
| WOOD BARRELL COOLER FOR MILK CANS, FLOW-THROUGH TYPE | ND C-833** | '20 | 1 | X | |
| HAY SELF FEEDERS & FEEDBNK; RAILFENCE, SLOPED SLAT-FL, SKIDS | ND CIRC AE | -42 '54 | 2 | X | |
| LAZY SUSAN FEEDBUNK, 14' DIAM, 1/2 HP, WOOD CONSTRUCTION | ND CIRC AE | -53 '56 | 2 | X | |
| GENERAL BARN, 34'X60', GbR, 15 COWS, 10 CALVES, HORSES | ND D-33-11 | ** '25 | 1 | X | |
| CATTLE FEEDBUNK, 3'X14' ON LEGS, MOVABLE | ND D-56-11 | * '26 | 1 |
